Electric motor controller Yiyun YK31C / YK40 / LBD14 500W 12V 24V 36V


Electric motor controller Yiyun YK31C / YK40 / LBD14 500W 12V 24V 36V

In stock

starting from 65.00
Price incl. VAT, plus Shipping
Delivery weight: 0.2 kg


Item name:

Electric motor controller DC 500W 12V/24V/36V


Brand:

Zhejiang Unite Electric Motor Co., Ltd.


Model/type & pictures:

YK31C (YK40 / LBD14)




stock photo






Performance data:

voltage

12V / 24V / 36V

threshold voltage

8.5V / 20V / 31V +/- 0,5V

power

<= 500 W

current

40A / 31A /31A +/- 1A




External dimensions:

length

10.4 cm

width

6.5 cm

height

3.7 cm



Further attributes:

-for 2-pole electric DC motors
-for motors with brushes and two cables

-CE certified
-housing material: aluminium
-mounting holes
-legal warranty: 24 month

Connection plan:



Note: Delivery includes fuse set.



Areas of applications:

This direct current electric motor controller is suitable e. g. for electric scooter, (SMFC) scooter, e-scooter, fun-scooter, trottinette, pocket bike, pocketbike, tricycle, quad bike, electric quad bike, kids quad bike, longboard, electric board, e-board, electric bike, e-bike, recumbent bike, soap-box, rickshaw, trishaw, Velotaxi, tensile device, tensile device for wheelchairs, electric wheelchair, railway, garden railway, small railway, big railway, steam railway, park railway, model railway, narrow gauge railway, cart, electric car, e-car, golf cart, hand bike, pedal boat, electric pedal boat, plane, helicopter, model making, miniature making, theater engineering, stage engineering, industry, machines... .
This DC Controller manages the whole board electric, like motor speed, light, controll lamp, charge input, brake, brake light... .



Available accessories:

Motor, lead acid battery, charger, throttle, pedal, relay, switch ...
